2mm headers to 2.5mm header

2mm header (SEO shenanigans)

Its a simple hack to use boards with 2mm spacing headers with the usual 2.5mm headers, the pictures are worth a thousand words. You can use this with your most esp8266 or xbees.

Steps

Measure

IMG-20131204-00473

Strip a wire, and give its a twist.



IMG-20131204-00474

Insert it from the solder side

IMG-20131204-00476

Solder it

IMG-20131204-00477

Snip it

IMG-20131204-00478

Do it again as per your need

IMG-20131204-00479

Done

IMG-20131204-00480

Place the 2mm header spacing board, move the wire with pliers where they need to be soldered

IMG-20131204-00481

Soldered

IMG-20131204-00482

Solder the 2.5mm headers

IMG-20131204-00488

x 2

IMG-20131204-00489

Use them as daughter boards.
